Product Description
- Product Name: NbTi Wire for ITER
- Standard: ASTM B884
- Description: We can supply NbTi strands with stable and mature production technology for ITER project. Also, we can provide customized and professional service with an aim to make your business a success.
- Performace of NbTi Strand (our NbTi strand can fully meet all ITER specifications.)
|
ITEMS |
ITER SPECIFICATIONS |
PERFORMANCE |
|
Unit length (m) |
>1000 |
Max.=90,000 |
|
Diameter (mm) |
0.730 ±0.005 |
0.727 -0.732 |
|
Twist pitch (mm) |
15 ±2 |
13.2-16.8 |
|
Ni thickness (um) |
2.0 +0,-1 |
1.3-1.6 |
|
Cu / Non-Cu |
2.35 ±0.1 |
2.28-2.34 |
|
Filament Number (pc) |
2600 |
2600 |
|
Filament diameter (um) |
≤8 |
7.8-8.0 |
|
RRR (273/10K) |
>100 |
110-160 |
|
Ic (A) @4.2K, 5T |
≥339 |
360-390 |
|
Qh (mJ/cm3) @4.2K, ±1.5T |
<45 |
35-45 |
- Product Name: NbTi Superconducting Wire for MRI
- Standard: ASTM B884
- Description: We have rich experience of manufacturing NbTi Superconducting Wire for MRI. Which it have stable quality and gain highly reputation from customers.
- Reference Performance
|
Cu: Sc Ration |
Filament |
Bare Size (mm) |
Insulation Size (mm) |
Ic (4.2K) (A) Test Result |
|||||
|
3T |
4T |
5T |
6T |
7T |
8T |
||||
|
2.5 |
54 |
1.016 |
1.067 |
/ |
/ |
680 |
540 |
399 |
254 |
|
3.0 |
42 |
1.0 *1.76 |
1.06*1.82 |
/ |
/ |
/ |
/ |
/ |
423.5 |
|
4.0 |
36 |
0.75*1.20 |
0.83*1.28 |
/ |
/ |
/ |
405.8 |
298.6 |
195.0 |
|
4.0 |
36 |
1.10*1.70 |
1.20*1.80 |
/ |
/ |
990.0 |
770.0 |
550.0 |
340.0 |
|
7.0 |
24 |
1.10*1.70 |
1.20*1.80 |
815.0 |
675.0 |
549.0 |
427.0 |
309.0 |
/ |
|
7.5 |
24 |
0.78*1.15 |
0.88*1.25 |
395.8 |
325.5 |
264.0 |
/ |
/ |
/ |
|
10.0 |
18 |
1.00*1.70 |
1.10*1.70 |
432.1 |
362.0 |
297.6 |
/ |
/ |
/ |
