Product Description
We are specialized in Titanium and alloys Cladding made by Explosive Cladding or Explosive-Rolled Cladding, have been supplied in various applications:
-Power Plant Desulphurization
-Pressure Vessels
-Power Station Auxiliary Equipment
-Chemical Industry
-Petrochemical Industry
-Coal-to-Liquid Industry
-Vacuum-Evaporation Salt Industry
-Desalination Plant, etc.
Clad Materials:
Clad can be produced with Titanium/Titanium alloy, Stainless Steel, Copper, Nickel, Aluminium, Steel by Explosion, Explosion-Rolling, and Rolling.
Clad Plate:
Configuration: Ti+Cu, Ti+Al, Ti+Ni, Ti+Steel, Ti+Stainless Steel Clad method: Explosion, Rolling, Explosion+Rolling
Part of Clad Products manufactured:
|
Products |
Clad Material |
Base Material |
Size (mm) |
Standard |
Application |
|
Ti/Carbon Steel Cladding |
ASTM B265 Gr.1, Gr.2, Gr.9, Gr.12 |
ASTM A572-Gr.50, ASTM A516-Gr.60, Gr.65, Gr.70 ASTM A287-Gr.A, Gr.B, Gr.C, Gr.D |
*B: (1~12)/(5~120)x≤4500x≤6500 **BR: (1~12)/(5~120)x≤3000x≤6500 |
ASTM B898 |
Petrochemical, Chemical, Vacuum Salt Production, Chlor-Alkali, Food Production, etc. |
|
Ti/Stainless Steel Cladding |
ASTM B265 Gr.1, Gr.2, Gr.9, Gr.12 |
ATSTM A240-410S |
(1~6)/(5~120)x≤2000x≤8000 |
ASTM B898 |
Petrochemical, Chlor- Alkali, Aerospace, Food production, Low- temperature application, Light Industry, Medical, etc. |
|
Ti/Aluminum Cladding |
ASTM B265 Gr.1, Gr.2, Gr.9, Gr.12 |
ASTM B209M-1060 |
(1~10)/(5~50)x≤2000x≤8000 |
ASTM B898 |
Aerospace, Kitchenware, Cooking Utensil, Chemical, Industrial, Special Brazing Metal, etc. |
|
Ti/Cu Cladding |
ASTM B265 Gr.1, Gr.2, Gr.9, Gr.12 |
ASTMB152M -C1100P ASTMB171M -C71500 |
(1~10)/(5~50)x≤2000x≤8000 |
ASTM B898 |
Power sector, Eletrolytic Industry, Cooking Utensil, Hydrometallurgy, etc. |
|
Ti/Nickel Cladding |
ASTM B265 Gr.1, Gr.2, Gr.9, Gr.12 |
ASTMB162-N02201 |
(1~10)/(5~50)x≤2000x≤8000 |
ASTM B898 |
Metallurgical Industry |
Our Services
Quality is the soul of our company!
We track every production process, inspect every single part, and record every step, for we know that "Quality first" is always our principle.
1.Provide third-part inspection reports.
2.Visual inspection to check surface quality, ensuring without flaw, black dot and any other defects.
3.Ultrasonic Flaw Detection making sure there are no defects inside.
4.Chemical Compositionmaking sure all chemical components can satisfy customer's demands
5.Mechanical Property testingmaking sure all titanium bars have satisfying mechanical features before delivery.
6.ISO Quality Management System-SGS test
